How to integrate with an external REST API and handle authentication errors gracefully — including expired tokens, invalid credentials, network issues, and unexpected response codes.

✅ Apex Class for REST Integration With Graceful Error Handling

🔹 Example Scenario

You are calling an external REST API with:

Bearer Token authentication
Need to auto-refresh token if it expires
Need robust error handling for API failures

✅ Apex REST Integration Class (with token refresh & graceful handling)

public with sharing class ExternalApiService {

    // Store auth token in custom metadata, custom setting, or named credentials
    // Here assuming a Custom Setting named ApiCredentials__c
    private static ApiCredentials__c creds = ApiCredentials__c.getOrgDefaults();

    // Base API URL
    private static final String BASE_URL = 'https://api.example.com/v1/';

    /**
     * Main method to perform GET request
     */
    public static String getData(String endpoint) {
        try {
            HttpRequest req = buildRequest('GET', endpoint, null);
            HttpResponse res = sendRequest(req);

            return handleResponse(res, 'GET ' + endpoint);
        }
        catch (Exception ex) {
            System.debug('Unexpected error: ' + ex.getMessage());
            throw new CalloutException('An unexpected error occurred: ' + ex.getMessage());
        }
    }

    /**
     * Build HTTP request object with headers and payload
     */
    private static HttpRequest buildRequest(String method, String endpoint, String body) {
        HttpRequest req = new HttpRequest();
        req.setMethod(method);
        req.setEndpoint(BASE_URL + endpoint);
        req.setTimeout(60000); // 60 seconds

        // Authorization header
        req.setHeader('Authorization', 'Bearer ' + creds.AccessToken__c);
        req.setHeader('Content-Type', 'application/json');

        if (body != null) {
            req.setBody(body);
        }
        return req;
    }

    /**
     * Core method to send HTTP callout with error fallback
     */
    private static HttpResponse sendRequest(HttpRequest req) {
        Http http = new Http();
        HttpResponse res = http.send(req);

        // If unauthorized, try refreshing the token once
        if (res.getStatusCode() == 401) {
            System.debug('Token expired. Refreshing token…');

            Boolean refreshed = refreshToken();
            if (refreshed) {
                // Retry the original request
                req.setHeader('Authorization', 'Bearer ' + creds.AccessToken__c);
                res = http.send(req);
            }
            else {
                throw new CalloutException('Authentication failed — unable to refresh token.');
            }
        }
        return res;
    }

    /**
     * Handle API response and throw meaningful errors
     */
    private static String handleResponse(HttpResponse res, String action) {
        Integer code = res.getStatusCode();
        String body = res.getBody();

        if (code >= 200 && code < 300) {
            return body;
        }
        else if (code == 400) {
            throw new CalloutException('Bad Request during ' + action + ': ' + body);
        }
        else if (code == 403) {
            throw new CalloutException('Forbidden: Check permissions on API.');
        }
        else if (code == 404) {
            throw new CalloutException('Endpoint not found: ' + action);
        }
        else if (code >= 500) {
            throw new CalloutException('Server error from external API: ' + code);
        }
        else {
            throw new CalloutException('Unexpected response (' + code + '): ' + body);
        }
    }

    /**
     * Refresh the access token
     */
    private static Boolean refreshToken() {
        try {
            HttpRequest req = new HttpRequest();
            req.setEndpoint('https://api.example.com/oauth/token');
            req.setMethod('POST');
            req.setHeader('Content-Type', 'application/x-www-form-urlencoded');

            String body = 'client_id=' + creds.ClientId__c +
                          '&client_secret=' + creds.ClientSecret__c +
                          '&grant_type=refresh_token' +
                          '&refresh_token=' + creds.RefreshToken__c;

            req.setBody(body);

            Http http = new Http();
            HttpResponse res = http.send(req);

            if (res.getStatusCode() == 200) {
                Map<String, Object> tokenData = (Map<String, Object>) JSON.deserializeUntyped(res.getBody());
                creds.AccessToken__c = (String) tokenData.get('access_token');
                creds.save();
                return true;
            }
            else {
                System.debug('Token refresh failed: ' + res.getBody());
                return false;
            }
        }
        catch (Exception ex) {
            System.debug('Token refresh exception: ' + ex.getMessage());
            return false;
        }
    }
}

JavaScript

📝 Full Explanation

Below is a deep explanation of how this Apex class works, suitable for documentation, interview prep, or Salesforce certification.

1. Purpose of the class

When integrating Salesforce with an external REST API, common issues arise:

✔ Token expiration

The access token can expire, causing 401 errors.

✔ Network issues

Timeout, connection failure, SSL issues.

✔ API errors

400 (invalid input),
403 (forbidden),
404 (invalid endpoint),
500/503 (server downtime).

✔ Need for safe fallback

Your apex class should not crash; it should return meaningful and safe error messages.

This class is designed exactly for that.

2. Using HttpRequest and Http classes

Salesforce sends outbound requests using HttpRequest and Http.

Key properties included:

setEndpoint()
setMethod()
setTimeout(60000) → prevents timeouts
setHeader('Authorization', 'Bearer ...')
setBody() for POST calls

3. Graceful handling of authentication errors

🔹 Step 1: Detect expired token

If API returns 401 Unauthorized, the token is probably expired.

🔹 Step 2: Attempt to refresh token once

Your code calls refreshToken() which:

Sends a POST request to /oauth/token
Retrieves a new access_token
Saves the token into Custom Setting / Metadata

🔹 Step 3: Retry original request

After refreshing token, the system retries the same API call.

🔹 Step 4: If still fails, throw a friendly message

throw new CalloutException('Authentication failed — unable to refresh token.');

JavaScript

4. Error-handling strategy

This code handles errors as follows:

Error Type	Handling
400 Bad Request	Returns detailed message indicating what caused the issue
403 Forbidden	Suggest permissions fix
404 Not Found	Endpoint incorrect
500+ API Server error	Graceful failure message
Timeout / Exceptions	Catch block returns safe fallback

5. Secure Storage of Credentials

Tokens and secrets should NOT be hardcoded.

Best options:

✔ Named Credentials (Recommended)

Automatically handles tokens.

✔ Custom Metadata Types

Good for org-wide settings.

✔ Hierarchy Custom Settings

Editable via UI.

This sample uses Custom Settings.

6. Retrying the request

The logic ensures max 1 retry to avoid loops.

7. Clean, reusable architecture

This class is reusable because:

Authentication is separate
Error handling centralized
Request builder method reusable
Supports GET, POST, PUT with small changes
